Antenna Routing - 911 Targa & Cabriolet
Antenna mounts through a hole drilled in the driver-side fender. Hole is 14mm in diameter. See Fig 1 . The antenna cable is routed from the antenna through the side section, marked by a punch point approximately 120 mm below the bore for the side indicator lamp, then along the passenger compartment wiring harness to the tunnel and on the left top edge of the tunnel to the receiving unit/antenna duplexer. See Figure .
