Check signal with engine tester

  1. Connect special tool 9637.
  2. Connect engine tester. Using special input, connect positive cable to pin III/32, negative cable to pin III/46.
  3. Start engine or crank engine with starter motor.

    The display pictured opposite should appear on the oscilloscope:

    Fig 1: Identifying Crankshaft Position Sensor Display
    G02534233Courtesy of PORSCHE OF NORTH AMERICA, INC.
