Belt tensioner

Connect the ignition device 9257 with the adapter cable 9257/3 to the belt tensioner. Place the ignition device in front of the vehicle through the door gap.

Fig 1: Identifying Ignition Tool (Belt Tensioner)
G03155365Courtesy of PORSCHE OF NORTH AMERICA, INC.
