Instrument Cluster

The instrument cluster consists of fuel gauge, low fuel indicator, washer fluid low level indicator, oil level gauge, engine oil temperature gauge, automatic brake differential indicator, central warning light, check engine light, ABS warning light, brake pressure warning light (if equipped), brake pad wear indicator, parking brake indicator, engine oil pressure warning light, brake fluid warning light, turn signal indicators, high beam indicator, central information panel (on-board computer), speedometer, tachometer, odometer, warning buzzer, clock set rocker switch and clock.

Speedometer range is from 0-180 MPH. The warning lights for safety belt warning, alternator warning, rear spoiler warning, convertible top indicator, air bag indicator, Tiptronic "S" indicator, parking light indicator, engine fan belt indicator and anti-drive off (immobilizer) feature are built into the clock. See Figure .
