Removal Procedure

WARNING: This page is about a different variant/trim than selected.
    Fig 1: Identifying Negative Battery Cables & Cable Components
    GM1717479Courtesy of GENERAL MOTORS CORP.
  1. Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection .
  2. Remove the tire and wheel. Refer to Tire and Wheel Removal and Installation .
  3. Remove the left engine mount. Refer to Engine Mount Replacement - Left Side .
  4. Remove the positive battery cable starter solenoid nut (2) from the starter.
  5. Remove the positive battery cable terminal (3) from the starter.
    6. Fig 2: Identifying Generator
    GM1717482Courtesy of GENERAL MOTORS CORP.
  6. Reposition the engine wiring harness boot (2) at the generator stud.
  7. Remove the engine wiring harness nut (1) from the generator.
  8. Remove the engine wiring harness terminal (3) from the generator.
    9. Fig 3: View Of Engine Mount Bracket
    GM1717065Courtesy of GENERAL MOTORS CORP.
  9. Remove the engine mount bracket bolts and bracket.
