Valve Lifter and Guide Cleaning and Inspection

WARNING: This page is about a different variant/trim than selected.
    Fig 1: Inspecting Valve Rocker Arm Subassembly
    GM2017084Courtesy of GENERAL MOTORS CORP.
  1. Inspect No. 1 valve rocker arm subassembly.
    2. NOTE: If the roller does not turn smoothly, replace the valve rocker arm sub-assembly.
  2. Turn the roller by hand to check that it turns smoothly.
    3. NOTE: Keep the lash adjuster free of dirt and foreign matter. Only use clean engine oil.
  3. Inspect valve lash adjuster assembly.
