Removal Procedure

WARNING: This page is about a different variant/trim than selected.
    Fig 1: Measuring Transmission Fluid Level
    GM2010110Courtesy of GENERAL MOTORS CORP.
  1. Remove the filler plug and the gasket.
  2. Remove the drain plug and gasket, and then drain the manual transaxle oil.
