Removal Procedure

WARNING: This page is about a different variant/trim than selected.
  1. Remove the engine cover assembly.
  2. Remove the air cleaner assembly.
    3. Fig 1: Identifying Starter Assembly Terminal 50 Connector
    GM2010452Courtesy of GENERAL MOTORS CORP.
  3. Disconnect the terminal 50 connector (1) from the starter assembly.
  4. Remove the nut and disconnect the wire harness from terminal 30.
    5. Fig 2: View Of Wire Harness Clamp
    GM2010455Courtesy of GENERAL MOTORS CORP.
  5. Disconnect the wire harness clamp.
    6. Fig 3: Locating Back-Up Light Switch Connector
    GM2010460Courtesy of GENERAL MOTORS CORP.
  6. Disconnect the back-up light switch connector (1).
    7. Fig 4: Locating Back-Up Light Switch At Transaxle Case
    GM2010464Courtesy of GENERAL MOTORS CORP.
  7. Remove the back-up light switch and gasket from the transaxle case.
