Door Lock and Side Window Switch Replacement - Passenger Side

WARNING: This page is about a different car, the 2009 Cadillac DTS. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: View Of Side Door Armrest Switch & Components

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	Side Door Armrest Switch Mount Plate Procedure Use a flat-trim tool to pry up on the switch assembly. Disconnect the electrical connectors.
2	Side Door Armrest Switch Mount Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
3	Door Lock and Side Window Switch Assembly Refer to Control Module References for replacement and setup information.

Callout

Component Name

Side Door Armrest Switch Mount Plate

Procedure

Use a flat-trim tool to pry up on the switch assembly.
Disconnect the electrical connectors.

Side Door Armrest Switch Mount Screw (Qty: 3)

CAUTION: Refer to Fastener Caution .

Tighten: 2 N.m (18 lb in)

Door Lock and Side Window Switch Assembly
Refer to Control Module References for replacement and setup information.
