Section 118 (Cruise Control System)
>>
Wiring Schematics
>>
Cruise Control Wiring Schematics
>>
ON/OFF Switch
ON/OFF Switch
WARNING:
This page is about a different car, the 2011 Cadillac DTS. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: ON/OFF Switch Wiring Schematic
Courtesy of GENERAL MOTORS COMPANY
