Power Sunroof Inoperative

Power Sunroof Inoperative

Diagnostic Aids

When testing the sunroof motor open or close control circuits, note the sunroof glass position. If the glass is in the full open or full vent position, any request to operate the glass beyond its limit, may result with no power output to the sunroof motor.
