Hood Hinge Replacement
WARNING: This page is about a different car, the 2009 Pontiac Torrent and 2009 Chevrolet Equinox. However, it is still accessible from the selected car via links, so may be relevant.
| Callout | Component Name |
|---|---|
| 1 | Hood Hinge Upper Bolt (Qty: 2)
CAUTION:
Refer to Fastener Caution
.
Tighten: 25 N.m (18 lb ft) |
| 2 | Hood Hinge Lower Bolt (Qty: 2) Tighten: 25 N.m (18 lb ft) |
| 3 | Hood Assembly
WARNING:
When a hood hold open device is being removed or installed, provide alternate support to avoid the possibility of damage to the vehicle or personal injury. Tip: Mark the location of the hinge to the hood with a grease pencil to aid in alignment. |
