Sunshade Replacement

Fig 1: View Of Sunshade & Bolt
GM1581537Courtesy of GENERAL MOTORS CORP.
Callout Component Name
1 Sunshade Assembly Bolt
NOTE: Refer to Fastener Notice .

Tighten:  6 N.m (53 lb in)
2 Sunshade Assembly
