Up/Down Adjustment Rear Edge of Hood (To Achieve Fit to the Doors & Fenders)

    Fig 1: View Of Rear Edge Of Hood Adjustment Area
    GM1769034Courtesy of GENERAL MOTORS CORP.
  1. Determine the amount of adjustment needed.
  2. Open the hood.
  3. Loosen the side hood latch.
  4. Reposition the hood latch.
  5. Tighten the hood latch bolts.

    Tighten:  Tighten to 25 N.m (19 lb ft).

  6. Inspect the hood alignment.
