Valve Lifter Removal

WARNING: This page is about a different variant/trim than selected.
    Fig 1: Identifying Valve Lifters & Guides
    GM41374Courtesy of GENERAL MOTORS CORP.
  1. Remove the valve lifter guide retainer bolts.
  2. Remove the valve lifter guide retainers.
  3. Remove the valve lifters.
