Removal Procedure

    Fig 1: View Of Hood Latch & Hood Latch Support
    GM1229678Courtesy of GENERAL MOTORS CORP.
  1. Remove the hood latch from the hood latch support. Refer to Hood Latch Replacement .
  2. Remove the front bumper fascia upper support bolts from the hood latch support.
  3. Remove the bolts from the hood latch support at the upper tie bar.
  4. Remove the nut from the hood latch support at the lower tie bar.
  5. Remove the hood latch support from the tie bar.
