LEMON Manuals
: Even more car manuals for everyone
Home
>>
Pontiac
>>
2007
>>
G6 L4-2.4L
>>
Repair and Diagnosis
>>
Diagrams
>>
Connector Views
>>
Multiple Junction Connector
>>
C400 - C499
>>
C415
C415
C415 Headliner Harness To Sunroof Harness (With RPO Code C3Y) (Pin A To J):
C415 Headliner Harness To Sunroof Harness (With RPO Code C3Y) (Pin K To M):
