Special Tools

WARNING: This page is about a different variant/trim than selected.

Special Tools

Illustration	Tool Number/Description
Courtesy of GENERAL MOTORS CORP.	J 2619-01 Slide Hammer
Courtesy of GENERAL MOTORS CORP.	J 7872 Magnetic Base Dial Indicator
Courtesy of GENERAL MOTORS CORP.	J 8092 Driver Handle
Courtesy of GENERAL MOTORS CORP.	J 8614-01 Countershaft Driven Gear Holder
Courtesy of GENERAL MOTORS CORP.	J 9617 Pump Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 22912-01 Bearing Split Plate
Courtesy of GENERAL MOTORS CORP.	J 23327 Clutch Spring Compressor
Courtesy of GENERAL MOTORS CORP.	J 26900-6 Dial Caliper
Courtesy of GENERAL MOTORS CORP.	J 26941 Countershaft Bearing Drive Axle Seal Remover
Courtesy of GENERAL MOTORS CORP.	J 34673 Flat Gage Bar
Courtesy of GENERAL MOTORS CORP.	J 34826 Hub Nut Socket-36 mm
Courtesy of GENERAL MOTORS CORP.	J 35287 Countershaft Bearing Race Installer
Courtesy of GENERAL MOTORS CORP.	J 35405 Differential Preload Wrench
Courtesy of GENERAL MOTORS CORP.	J 35421 Rack End Bushing Installer
Courtesy of GENERAL MOTORS CORP.	J 35425 Rack Seal and Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 35552 Differential Side Bearing Cup Installer
Courtesy of GENERAL MOTORS CORP.	J 35683 First and Reverse Brake Piston Compressor
Courtesy of GENERAL MOTORS CORP.	J 36513 Large Bearing Split Plate
Courtesy of GENERAL MOTORS CORP.	J 36850 Transjel® Lubricant
Courtesy of GENERAL MOTORS CORP.	J 37271 Countershaft Locknut Spanner Wrench
Courtesy of GENERAL MOTORS CORP.	J 37273 Countershaft Pressing Button
Courtesy of GENERAL MOTORS CORP.	J 37278 Countershaft Inner Race Support Disc
Courtesy of GENERAL MOTORS CORP.	J 37279 Clutch Spring Compressor
Courtesy of GENERAL MOTORS CORP.	J 37282 Piston Brake Compressor
Courtesy of GENERAL MOTORS CORP.	J 37758 Countershaft Rear Plug Installer
Courtesy of GENERAL MOTORS CORP.	J 38358-A Support Remover/Installer
