Installation Procedure
- Insert the key into the lock cylinder.
- Align the lock cylinder in the same position used for removal. Push the cylinder in place to seat fully.
- Turn the key 1/4 turn clockwise to secure the lock cylinder retainer.
- Remove the key from the lock cylinder.
- Inspect the operation of the lock cylinder. The lock cylinder should only allow a 1/4 turn and should be securely retained in the door handle.
- Align and install the IP compartment latch to the IP compartment.NOTE: Refer to FASTENER NOTICE .
- Install the IP compartment latch screws.
Tighten
Tighten the IP compartment latch screws to 2 N.m (18 lb in).
- Close the IP compartment door.
