Test Description

The number(s) below refer to the step number(s) on the diagnostic table.

  1. 3.   Tests for the proper operation of the circuit in the high voltage range.
    Fig 1: DTC P0462
    G01721670Courtesy of GENERAL MOTORS CORP.
