Diagnostic Aids
An intermittent condition is likely to be caused by a short between circuit No. 347 and circuit No. 348 or 1403, or a malfunctioning shorting clip at base of steering column. Test for diagnostic trouble code is only run while AIR BAG warning light is performing bulb check. When a scan tool CLEAR CODES command is issued and malfunction is still present, DTC will not reappear until next ignition cycle.
WARNING:
To avoid air bag deployment and injury when trouble shooting system, only use test equipment specified in diagnostic charts. Under no circumstances should battery powered test equipment or test light be used. Carefully follow all instructions.
