Rear Wheel Stud: Installation
- Install new stud (insert from back side of hub). See Fig 1 .
- Install four flat washers on stud.
- Install wheel nut with flat side toward washers.
- Tighten nut until stud head is properly seated in hub flange.
- Install brake drum.
- Install tire and wheel assembly. Tighten lug nuts to specification. See TORQUE SPECIFICATIONS .
- Remove support and lower vehicle.
