Lower Ball Joint

Support vehicle by placing jack under cradle. Grab wheel at top and bottom and move it in-and-out. If there is horizontal movement between control arm and knuckle, replace ball joint.

Fig 1: Fiero Rear Suspension Assembly
G27035
