Instrument Cluster: Chrysler
Remove instrument panel upper cover by lifting rearward edge of cover to free mounting clips then lift cover rearward, up, and off. Working through hole in top of panel, disconnect speedometer cable and round printed circuit board connector. Place gear selector in "L" position. Remove ash tray and while holding trip odometer reset shaft with needle nose pliers, remove reset shaft knob. Remove gear selector bezel by pulling it from the panel (Brougham), or removing bezel retaining screws (Chrysler). Remove screws along bottom edge of cluster bezel. Center temperature control lever. Disengage clips along top of bezel by pulling bezel out. Disconnect electrical lead and remove bezel. Remove cluster lens by rolling it out from the top. Remove cluster-to-carrier screws and pull cluster assembly out enough to disconnect lights, modules, and wires. Remove cluster assembly. To install, reverse removal procedure.
