Brake Rotor: Installation
Slide brake disc and hub assembly on spindle. Install outer bearing, thrust washer and nut. Adjust wheel bearing to specifications. Clean both sides of braking disc with alcohol or suitable solvent. Install caliper assembly.
Courtesy of CHRYSLER GROUP, LLC
