Test Description

The numbers below refer to the step numbers on the diagnostic table.

  1. 3. Tests for the proper operation of the circuit in the high voltage range.
    Fig 1: DTC P0462 Diagnostic Table
    G01830813Courtesy of GENERAL MOTORS CORP.
