Exploded View
WARNING: This page is about a different variant/trim than selected.
 Courtesy of NISSAN NORTH AMERICA, INC.
|
|
1.
|
Parking actuator support
|
2.
|
Parking pawl
|
3.
|
Return spring
|
|
4.
|
Pawl shaft
|
5.
|
Parking gear
|
6.
|
Seal ring
|
|
7.
|
Output shaft
|
8.
|
Bearing race
|
9.
|
Needle bearing
|
|
10.
|
Self-sealing bolt
|
11.
|
Bracket
|
12.
|
Rear extension
|
