Exploded View
WARNING: This page is about a different variant/trim than selected.
 Courtesy of NISSAN NORTH AMERICA, INC.
|
|
1.
|
A/T assembly
|
2.
|
Oil pan gasket
|
3.
|
Oil pan
|
|
4.
|
Clip
|
5.
|
Oil pan mounting bolt
|
6.
|
Overflow plug
|
|
7.
|
Drain plug
|
8.
|
Drain plug gasket
|
9.
|
Magnet
|
|
10.
|
Output speed sensor
|
11.
|
Self-sealing bolt
|
12.
|
Bracket
|
|
13.
|
Rear extension
|
