Exploded View
WARNING: This page is about a different variant/trim than selected.
Courtesy of NISSAN NORTH AMERICA, INC.
|
1.
|
Pilot converter
|
2.
|
Drive plate
|
3.
|
Reinforcement plate
|
|
4.
|
O-ring
|
5.
|
Crankshaft position sensor (POS)
|
6.
|
Transmission
|
|
A.
|
Chamfered
|
B.
|
Installed on transmission
|
|
Crankshaft side
|
