Exploded View
WARNING: This page is about a different car, the 2020 Infiniti QX60. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of NISSAN NORTH AMERICA, INC.
|
1.
|
Seal bearing
|
2.
|
Front exhaust tube
|
3.
|
Ring gasket
|
|
4.
|
Front exhaust tube bracket
|
5.
|
Center exhaust tube rubber hanger
|
6.
|
Center exhaust tube
|
|
7.
|
Rear exhaust tube
|
8.
|
Rear exhaust tube rubber hanger
|
9.
|
Gasket
|
|
|
Front
|
