Exploded View

WARNING: This page is about a different car, the 2020 Infiniti QX60. However, it is still accessible from the selected car via links, so may be relevant.

Courtesy of NISSAN NORTH AMERICA, INC.

1.	ECM cover	2.	ECM bracket	3.	ECM
	Front

Courtesy of NISSAN NORTH AMERICA, INC.

1.	ECM bracket	2.	ECM	3.	ECM cover
	Front
