Removal and Installation: Removal

WARNING: This page is about a different car, the 2019 Nissan NV3500 HD, 2019 Nissan NV2500 HD, and 2019 Nissan NV1500. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the wheel and tire assembly using power tool. Refer to Adjustment .
  2. Remove the stabilizer bar connecting rods and position the stabilizer bar downward to gain access to the shock absorber lower bolt. Refer to Removal and Installation .
  3. Support the knuckle and the lower link using a suitable jack.
  4. Remove the shock absorber lower bolt (A) and nut (B).
    GNSAWEIA0223Z-223Courtesy of NISSAN NORTH AMERICA, INC.
    CAUTION: Do not reuse the shock absorber lower nut.
  5. Remove the three shock absorber upper nuts (A).
    GNSALEIA0116Z-116Courtesy of NISSAN NORTH AMERICA, INC.
  6. Remove the coil spring and shock absorber assembly from the vehicle.
    CAUTION: Use care around the wheel sensor wiring harness and brake hose during the removal of the coil spring and shock absorber assembly.
