Oil Leakage Inspection

WARNING: This page is about a different car, the 2019 Nissan NV3500 HD, 2019 Nissan NV2500 HD, and 2019 Nissan NV1500. However, it is still accessible from the selected car via links, so may be relevant.

If oil (A) does not extend beyond the spring seat (B) or upper half (C) of strut/shock absorber (1), this is slight oil seepage and the strut/shock absorber should not be replaced.

Courtesy of NISSAN NORTH AMERICA, INC.
If oil (A) does extend beyond the spring seat (B) or upper half (C) of strut/shock absorber (1) as shown, perform the following.

Courtesy of NISSAN NORTH AMERICA, INC.
- Use a finger to touch the oil that has extended beyond the spring seat or upper half of strut/shock absorber.
- If the oil layer is thick and contains large pieces of dust and debris, replace the strut/shock absorber.
- If the oil layer is thin and does not contain large pieces of dust and debris, do not replace the strut/shock absorber.

NOTE: If strut/shock absorber leakage is diagnosed in one strut/shock absorber, do not automatically replace both sides. Replace only the leaking strut/shock absorber.
