Crash Zone Sensor
WARNING: This page is about a different car, the 2019 Nissan NV3500 HD, 2019 Nissan NV2500 HD, and 2019 Nissan NV1500. However, it is still accessible from the selected car via links, so may be relevant.
The crash zone sensor is located behind the front grill on the center radiator support. The crash zone sensor sends signals to the air bag diagnosis sensor unit during a frontal collision. This sensor may be identified by a yellow connector.
 Courtesy of NISSAN NORTH AMERICA, INC.
|
