Exploded View
WARNING: This page is about a different car, the 2019 Nissan NV3500 HD, 2019 Nissan NV2500 HD, and 2019 Nissan NV1500. However, it is still accessible from the selected car via links, so may be relevant.
|
1. |
Defroster nozzle |
2. |
Side defroster duct (LH) |
3. |
Center ventilator duct |
|
4. |
Front heating and cooling unit assembly |
5. |
Floor connector duct (LH) (if equipped) |
6. |
Front floor duct (LH) (if equipped) |
|
7. |
Front floor duct (RH) (if equipped) |
8. |
Floor connector duct (RH) (if equipped) |
9. |
Side defroster duct (RH) |
|
|
Front |
