Exploded View
WARNING: This page is about a different car, the 2019 Nissan NV3500 HD, 2019 Nissan NV2500 HD, and 2019 Nissan NV1500. However, it is still accessible from the selected car via links, so may be relevant.
|
1. |
Cowl top cover (RH) |
2. |
Cowl top side seal (RH) |
3. |
Cowl top center seal |
|
4. |
Cowl top extension bracket (RH) |
5. |
Drain tubes |
6. |
Cowl top extension |
|
7. |
Cowl top extension bracket (LH) |
8. |
Washer nozzle and hose assembly |
9. |
Cowl top side seal (LH) |
|
10. |
Cowl top cover (LH) |
A. |
Clip CG104 |
B. |
Clip CF110 |
|
C. |
Bolts |
