Oil Pump: Disassembly
WARNING: This page is about a different car, the 2019 Nissan NV3500 HD, 2019 Nissan NV2500 HD, and 2019 Nissan NV1500. However, it is still accessible from the selected car via links, so may be relevant.
- Remove oil pump housing from oil pump cover.
 Courtesy of NISSAN NORTH AMERICA, INC.
|
- Remove oil pump housing oil seal with a flat-bladed screwdriver.
 Courtesy of NISSAN NORTH AMERICA, INC.
|
CAUTION:
Be careful not to scratch oil pump housing.
- Remove O-ring from oil pump housing.
 Courtesy of NISSAN NORTH AMERICA, INC.
|
CAUTION:
Do not reuse O-ring.
- Remove O-ring from oil pump cover.
 Courtesy of NISSAN NORTH AMERICA, INC.
|
CAUTION:
Do not reuse O-ring.
