A/T Fluid Check
WARNING: This page is about a different car, the 2019 Nissan NV3500 HD, 2019 Nissan NV2500 HD, and 2019 Nissan NV1500. However, it is still accessible from the selected car via links, so may be relevant.
Fluid Leakage and Fluid Level Check
- Inspect for fluid leakage and check the fluid level. Refer to Checking A/T Fluid .
Fluid Condition Check
Inspect the fluid condition.
|
Fluid condition |
Conceivable Cause |
Required Operation |
|
Varnished (viscous varnish state) |
Clutch, brake scorched |
Replace the ATF and check the A/T main unit and the vehicle for malfunctions (wire harnesses, cooler pipes, etc.) |
|
Milky white or cloudy |
Water in the fluid |
Replace the ATF and check for places where water is getting in. |
|
Large amount of metal powder mixed in |
Unusual wear of sliding parts within A/T |
Replace the ATF and check for improper operation of the A/T. |
