Exploded View

WARNING: This page is about a different car, the 2019 Infiniti QX60. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Rear Suspension Arm Components With Torque Specification (For USA With AWD)

Courtesy of NISSAN NORTH AMERICA, INC.

1.	Rear suspension arm	2.	Connecting rod	3.	Rear suspension member
4.	Stabilizer bar	5.	Rear knuckle	6.	Cotter pin
	Front

Fig 2: Rear Suspension Arm Components With Torque Specification (Except For USA With AWD)

Courtesy of NISSAN NORTH AMERICA, INC.

1.	Rear suspension arm	2.	Connecting rod	3.	Rear suspension member
4.	Stabilizer bar	5.	Rear knuckle		Front
