Removal and Installation: Removal

WARNING: This page is about a different car, the 2019 Infiniti QX60. However, it is still accessible from the selected car via links, so may be relevant.

Remove rear propeller shaft from the torsional damper, and support the end of the propeller shaft. Refer to Exploded View .
Remove torsional damper lock nuts ( ), using suitable tool.

Fig 1: Torsional Damper Components With Torque Specification
Courtesy of NISSAN NORTH AMERICA, INC.

: Front
Remove torsional damper.
