Exploded View

WARNING: This page is about a different car, the 2019 Infiniti QX60. However, it is still accessible from the selected car via links, so may be relevant.

Courtesy of NISSAN NORTH AMERICA, INC.

1.	Front bumper fascia upper bracket (RH)	2.	Front bumper side bracket (RH)	3.	Front bumper reinforcement support (RH)
4.	Front bumper reinforcement	5.	Front energy absorber	6.	Front bumper fascia hood seal
7.	Front bumper fascia inner stiffener (LH)	8.	Front bumper fascia inner stiffener (RH)	9.	Front fog lamp (RH)
10.	Front sonar sensor outer [RH (if equipped)]	11.	Front fog lamp finisher (RH)	12.	Tow cover
13.	Front sonar sensor inner [RH (if equipped)]	14.	Front spoiler	15.	Front sonar sensor inner [LH (if equipped)]
16.	Front lower grille	17.	Front fog lamp finisher (LH)	18.	Front license plate bracket
19.	Front sonar sensor outer [LH (if equipped)]	20.	Front bumper fascia	21.	Front fog lamp (LH)
22.	Front bumper fascia upper retainer bracket	23.	Front bumper reinforcement support (LH)	24.	Front bumper fascia upper bracket (LH)
25.	Front bumper side bracket (LH)	26.	Core support cover	A.	Clip
	Pawl
