Exploded View

WARNING: This page is about a different car, the 2018 Nissan Titan XD and 2018 Nissan Titan. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Front Final Drive With Torque Specifications
GNSALDIA0725Z-725Courtesy of NISSAN NORTH AMERICA, INC.

1.

Front final drive assembly

2.

Front cross member assembly

3.

Front under cover

SYMBOL : Front
