Information Display (If Equipped)
WARNING: This page is about a different car, the 2018 Nissan Titan XD and 2018 Nissan Titan. However, it is still accessible from the selected car via links, so may be relevant.
A low tire pressure warning or flat tire warning is shown on the vehicle information display when they are transmitted from the low tire pressure warning control unit to combination meter via CAN communication.
|
Condition |
Vehicle information display |
|
|
Ignition switch OFF |
Not indicated |
|
|
Ignition switch ON |
Low tire pressure warning lamp remains ON after blinking for one minute. Tire Pressure Monitoring System (TPMS) malfunction. |
Not indicated |
|
Ignition switch ON |
Low tire pressure warning lamp remains ON (low tire pressure). |
Indicated |
|
Ignition switch ON |
Flat tire warning. |
Indicated |
