Removal and Installation: Removal
WARNING: This page is about a different car, the 2018 Nissan Maxima. However, it is still accessible from the selected car via links, so may be relevant.
- Open glass lid and sunshades.
- Remove the headlining. Refer to Removal and Installation .
- Release front sunshade rail (1) from sunshade drive post (2).
: Front
- Release rear sunshade rail from sunshade drive post.
- Remove side curtain air bag module bolts (two on each (LH/RH) sides) for access.
- Release harness clips from sunshade carrier assembly.
- Remove the center bracket bolts, then remove the center brackets (LH/RH).
- Remove the sunshade carrier assembly bolts, then lower sunshade and remove from vehicle.
- Release the end key slot from the sunshades.
