Exploded View

WARNING: This page is about a different car, the 2018 Nissan Maxima. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Transverse Link With Torque Specifications
GNSAWEIA0414Z-414Courtesy of NISSAN NORTH AMERICA, INC.

1.

Transverse link

2.

Front suspension member

SYMBOL

Front
