REAR STABILIZER : Exploded View
|
1. |
Stabilizer bar |
2. |
Stabilizer bushing |
3. |
Stabilizer clamp |
|
4. |
Stabilizer connecting rod |
5. |
Suspension arm |
||
|
|
|||||
|
Refer to HOW TO USE THIS INFORMATION : Repair Information . for symbols in the figure. |
|||||
