FUEL INJECTOR AND FUEL TUBE : Exploded View
WARNING: This page is about a different variant/trim than selected.
|
1. |
Clip |
2. |
Fuel feed hose bracket |
3. |
Seal ring |
|
4. |
Injector holder |
5. |
Backup ring |
6. |
O-ring |
|
7. |
Fuel injector |
8. |
Fuel rail pressure sensor |
9. |
O-ring |
|
10. |
High pressure fuel rail protector |
11. |
Fuel rail insulator |
12. |
High pressure fuel rail |
|
13. |
High pressure fuel tube |
14. |
O-ring |
15. |
High pressure fuel pump |
|
16. |
High pressure fuel pump insulator |
17. |
Fuel feed hose |
A. |
Refer to Removal and Installation . |
|
B. |
Refer to Removal and Installation . |
CAUTION:
Do not remove or disassemble parts unless instructed as shown.
