Main Harness

Courtesy of NISSAN NORTH AMERICA, INC.

A3	M1	GR/4	: Eco mode switch	E2	M83	W/20	: Audio unit
B3	M2	B/8	: Sport mode switch	A2	M84	W/4	: Joint connector-M32
B2	M3	W/8	: Meter control switch	A2	M85	W/8	: Joint connector-M33
C2	M4	W/4	: NATS antenna amp. (With Intelligent Key system)	E2	M86	W/8	: Joint connector-M34
C1	M5	W/4	: Dongle unit	D2	M87	W/32	: Audio unit
E2	M6	GR/24	: Joint connector-M01	D2	M88	W/8	: Audio unit
G4	M8	W/6	: To B106	E4	M89	B/6	: USB interface
B4	M9	W/16	: To M251	G2	M91	W/24	: To D101
E4	M10	Y/28	: Air bag diagnosis sensor unit	E3	M94	W/6	: Automatic drive positioner control unit
E3	M12	B/4	: Room lamp relay	D3	M95	L/4	: Heated steering relay
B1	M13	W/3	: Optical sensor	F3	M96	W/24	: Chassis control module
F2	M14	W/4	: Joint connector- M30	E2	M98	W/8	: Joint connector-M22
E4	M15	GR/2	: Inside key antenna (Instrument center)	B4	M100	W/10	: AWD lock switch
C2	M17	W/8	: Push-button ignition switch	D3	M101	W/20	: AV control unit (Without BOSE audio system)
B2	M18	GR/40	: BCM (Body control module)	C2	M102	W/24	: AV control unit (Without BOSE audio system)
B3	M19	B/40	: BCM (Body control module)	D4	M104	W/4	: Aux in jack
B2	M20	BR/16	: BCM (Body control module)	C3	M105	W/2	: Key switch
C3	M22	W/16	: Data link connector	D2	M106	W/8	: AV control unit (With BOSE audio system)
G1	M23	W/2	: Front tweeter RH	D4	M107	W/16	: CVT shift selector
C3	M25	W/3	: NATS antenna amp. (With Intelligent Key system)	D3	M108	W/20	: AV control unit (With BOSE audio system)
D2	M26	W/4	: Hazard switch	D2	M109	W/24	: AV control unit (With BOSE audio system)
A2	M27	W/8	: Joint connector-M13	G2	M112	W/40	: Around view monitor control unit
C2	M28	W/16	: Combination switch	B1	M122	-	: Body ground
F2	M29	W/16	: 3CH CAN gateway	D1	M123	W/6	: To M132
C3	M30	W/12	: Combination switch (Spiral cable)	C1	M125	W/32	: To M127
A4	M31	SMJ	: To E152	D1	M127	W/32	: To M125
C2	M32	W/4	: Ignition switch	C4	M128	B/6	: Intake door motor
A2	M33	W/8	: Fuse block (J/B)	C4	M131	B/6	: Mode door motor
B3	M34	SMJ	: To E153	D1	M132	W/6	: To M123
E2	M35	B/40	: TCU	D2	M133	GR/4	: Variable blower control (With auto A/C)
F3	M36	SMJ	: To B136	D2	M134	GR/2	: Variable blower control (With auto A/C)
B3	M37	W/2	: Combination switch (Spiral cable)	C3	M135	GR/2	: Intake sensor
E2	M38	W/6	: Joint connector-M05	E3	M136	B/6	: Air mix door motor
E1	M39	W/6	: Joint connector-M06	E3	M140	B/6	: Air mix door motor RH
D3	M41	W/2	: In-vehicle sensor	C4	M143	B/6	: Mode door motor
D3	M42	W/2	: Circuit breaker-1	E1	M144	W/2	: Front blower motor
C1	M43	B/20	: Joint connector-M02	F3	M145	B/6	: Air mix door motor LH
A2	M44	W/16	: Fuse block (J/B)	C2	M146	W/4	: Variable blower control (With manual A/C A/C)
C1	M47	B/20	: Joint connector-M04	C4	M147	B/6	: Intake door motor
C2	M48	B/2	: EPS control unit	G2	M148	W/24	: ADAS control unit
C2	M49	W/8	: EPS control unit	F2	M149	W/2	: Warning system buzzer
D3	M50	W/32	: Front air control	C1	M150	G/8	: Joint connector-M07
E3	M51	B/8	: A/C switch	E1	M151	W/6	: Joint connector-M40
A4	M52	W/16	: To B43	F1	M152	W/6	: Joint connector-M41
B3	M53	GR/4	: Combination switch (Spiral cable)	F1	M153	W/4	: Joint connector-M42
E4	M54	B/40	: A/C auto amp.	E1	M154	W/4	: Joint connector-M43
E4	M55	GR/40	: A/C auto amp.	F1	M155	W/4	: Joint connector-M44
C3	M56	GR/8	: Steering angle sensor	A1	M156	W/24	: To R11
B1	M57	-	: Body ground	D4	M157	B/4	: Front passenger air bag off indicator
E3	M58	B/4	: Power window relay	G3	M158	W/16	: To D102
F2	M59	W/2	: Glove box lamp	G3	M159	Y/4	: To D103
G2	M61	-	: Body ground	F1	M160	W/4	: Joint connector-M45
E4	M62	B/3	: Front power socket	G1	M161	W/4	: Joint connector-M37
E5	M63	B/3	: Console power socket	E1	M162	W/4	: Joint connector-M38
D1	M64	B/2	: Sunload sensor	E1	M163	W/4	: Joint connector-M39
E3	M65	W/8	: Joint connector-M26	G1	M164	W/4	: Joint connector-M36
B2	M66	W/8	: Heated steering wheel switch	A3	M167	W/16	: To D2
E2	M67	W/8	: Joint connector-M27	A3	M168	W/24	: To D3
A2	M68	BR/16	: Fuse block (J/B)	A3	M169	Y/4	: To D13
A4	M69	W/32	: To B41	D2	M170	W/8	: Joint connector-M29
D1	M70	BR/2	: Center speaker	E2	M171	W/4	: Joint connector-M25
C1	M71	B/20	: Joint connector-M03	G2	M172	W/4	: Joint connector-M31
F3	M72	W/2	: Circuit breaker-2	E2	M173	G/6	: TCU
C2	M73	W/8	: Joint connector-M23	E2	M193	W/8	: Joint connector-M18
B4	M74	W/16	: To B42	E5	M196	BR/6	: Front heated seat switch RH
A4	M75	B/2	: To E36	C5	M197	W/6	: Front heated seat switch LH
B2	M76	W/40	: Combination meter	Main sub harness
C2	M77	W/12	: Combination meter	B4	M251	W/16	: To M9
D1	M78	W/8	: Joint connector-M28	B4	M252	W/10	: AWD lock switch
A3	M79	B/8	: VDC off switch	B4	M254	GR/10	: Hill descent control switch
B1	M80	W/2	: Front tweeter LH	B4	M255	W/8	: Warning system switch
F1	M81	O/2	: Front passenger air bag module	B2	M256	G/8	: Automatic back door switch
E1	M82	B/2	: Front passenger air bag module	B2	M257	B/10	: Automatic back door main switch
