Front Seat LH Harness
| B200 | BR/12 | : To B57 | B211 | B/2 | : Lumbar motor | |
| B201 | W/16 | : To B52 | B212 | B/2 | : Seat back heater LH | |
| B202 | W/6 | : To B92 | B213 | W/32 | : Driver seat control unit | |
| B205 | W/10 | : Power seat switch LH (Without automatic drive positioner) |
B214 | W/12 | : Driver seat control unit | |
| B206 | B/5 | : Sliding motor LH (Without automatic drive positioner) |
B215 | BR/10 | : Power seat switch LH (With automatic drive positioner) |
|
| B207 | W/5 | : Reclining motor LH (Without automatic drive positioner) |
B216 | B/5 | : Sliding motor LH (With automatic drive positioner) |
|
| B208 | W/5 | : Lifting motor LH (Without automatic drive positioner) |
B217 | B/5 | : Reclining motor LH (With automatic drive positioner) |
|
| B209 | W/3 | : Front seat heater LH | B218 | B/5 | : Lifting motor LH (With automatic drive positioner) |
|
| B210 | BR/4 | : Power lumbar switch |
