Front Door LH Harness
| D2 | W/16 | : To M167 | D12 | Y/2 | : Front door satellite sensor LH | |
| D3 | W/24 | : To M168 | D13 | Y/4 | : To M169 | |
| D5 | W/8 | : Joint connector-D01 | D14 | W/16 | : Door mirror LH (Without automatic drive positioner) |
|
| D6 | W/16 | : Main power window and door lock/unlock switch |
D15 | W/8 | : Seat memory switch | |
| D7 | W/2 | : Front door speaker LH (Without BOSE audio system) |
D16 | W/16 | : Door mirror LH (With automatic drive positioner) |
|
| D8 | W/3 | : Main power window and door lock/unlock switch |
D22 | GR/16 | : Door mirror remote control switch (With automatic drive positioner) |
|
| D9 | BR/2 | : Front door speaker LH (With BOSE audio system) |
D23 | GR/6 | : Front door lock assembly LH | |
| D10 | G/6 | : Front power window motor LH | D27 | B/16 | : Door mirror remote control switch (Without automatic drive positioner) |
|
| D11 | B/4 | : Front outside handle assembly LH | D29 | W/4 | : Blind spot warning indicator LH |
